L2 L3 L4 12AWG 6AWG Rhh/Rhw 90c Dry and 75c Wet FT4-St1 Telecom Power Wire and Cable
L2 L3 L4 12AWG 6AWG Rhh/Rhw 90c Dry and 75c Wet FT4-St1 Telecom Power Wire and Cable image
Get Latest Price Request a quote
You May Like
Product Details
Model NO.
L2 L3 L4Telecommunications Power System
Application
Underground
Conductor Material
Tinned Copper
Sheath Material
Flame Retardant Polyolefin
Insulation Material
Flame Retardant Polyolefin
Material Shape
Round Wire
Range of Application
Flame Retardant
Certification
ISO9001, CE, CCC, RoHS, VDE, cUL
Brand
Zenda
Transport Package
Wooden Drum
Specification
L2 L3 L4
Trademark
HT Cables
Origin
China
HS Code
8544492100
Production Capacity
200000/Week
Product Description
L3 8AWG 6AWG RHH/RHW 90C DRY AND 75C WET FT4-ST1 Telecom Power Wire and Cable
Application
This specification covers the construction requirements for a limited smoke, non-halogenated power cable insulated. UL listed Type RHH, FT4-ST1 in accordance with the National Electrical Code. Product is for use in Central Office, CATV Head End, Data Center and Cell tower applications. Cable is suitable for UL “CT USE” (Cable Tray rated) in sizes 1/0AWG and large.
Conductor
Class I modified bunched (8 and 6 AWG) or rope bunched (4 AWG and larger) tinned copper.
Separator
Mylar tape
Insulation
Limited smoke, non-halogenated, 105°C Dry, 60°C Wet.
Operating voltage
Max 600 V
Operating temperature
Max 90 ºC, dry
Fire resistance
Specification
ASTM B-33 and B-172 Class I tinned copper
• UL 44 Type RHH, FT4-ST1, VW-1, 600 Volts DC or AC
• List 2
• UL 2731 Telecommunications Central Office Power Cable
• ATIS-0600017.2014 Non-Halogenated DC Power Wire and Cable for Telecommunications Power Systems
• CSA AWM IB 105°C 600V. FT4-ST1
• Lead-Free, Silicone-Free, RoHS Complaint
• IEC including 60674 and 60332
Technical data
| SIZE | STRANDING | NOMINAL CONDUCTOR DIAMETER (INCHES) | INSUL. MIN. AVG. WALL (MILS) | NOMINAL INSUL. DIAM. (INCHES) | MAX D.C RES @ 20°C (OHMS/MFT) | AMPACITY |
| 90°C | ||||||
| 14 | 41 | 0.077 | 45 | 0.17 | 2.73 | 25 |
| 12 | 65 | 0.089 | 45 | 0.182 | 1.72 | 30 |
| 10 | 104 | 0.116 | 45 | 0.209 | 1.08 | 40 |
| 8 | 41 | 0.153 | 60 | 0.28 | 0.679 | 55 |
| 6 | 65 | 0.186 | 60 | 0.315 | 0.436 | 75 |
| 4 | 126 | 0.26 | 60 | 0.365 | 0.274 | 95 |
| 2 | 168 | 0.305 | 60 | 0.43 | 0.172 | 130 |
| 1 | 210 | 0.37 | 80 | 0.54 | 0.126 | 150 |
| 1/0 | 266 | 0.392 | 80 | 0.56 | 0.109 | 170 |
| 2/0 | 342 | 0.455 | 80 | 0.62 | 0.0565 | 195 |
| 4/0 | 532 | 0.577 | 80 | 0.745 | 0.0546 | 260 |
| 350 | 888 | 0.76 | 95 | 0.96 | 0.0334 | 350 |
| 500 | 1221 | 0.89 | 95 | 1.09 | 0.0234 | 430 |
| 750 | 1850 | 1.094 | 110 | 1.32 | 0.0157 | 535 |
We are China L2 L3 L4 12AWG 6AWG Rhh/Rhw 90c Dry and 75c Wet FT4-St1 Telecom Power Wire and Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
