N2xs (FL) 2y/Na2xs (FL) 2y 12/20 Kv RM 1X300/25 1X400/50mm2 Cable
N2xs (FL) 2y/Na2xs (FL) 2y 12/20 Kv RM 1X300/25 1X400/50mm2 Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Product Description
NA2XS2Y / NA2XS(F)2Y / NA2XS(FL)2Y Cables
Hongda Cable also supplies the NA2XS(F)2Y and NA2XS(FL)2Y with single and double layers water blocking tape for additional water resistance.
NA2XS2Y / NA2XS(F)2Y / NA2X(FL)2Y CABLE CONSTRUCTION
Other than for its aluminium conductor, the NA2XS2Y shares the same cable construction as its copper variant, the N2XS2Y cable. Both cables are manufactured to VDE 0276-620, HDE 620 and DIN EN 60228.
This makes NA2XS2Y a cost-efficient alternative to its copper variant on installations where space is not an issue due to the larger overall diameter of aluminium cables.
NA2XS(F)2Y / NAXS(FL)2Y water blocking properties
| NA2XS(F)2Y | Swelling powder on tape | Longitudinally watertight |
| NA2XS(FL)2Y | Swelling powder on tape + Aluminium tape tightly bonded to the PE Sheath | Longitudinally and radially watertight |
Construction Table
| 2XS2Y ALUMINIUM CONDUCTOR XLPE PE | NA2XS(F)2Y ALUMINIUM CONDUCTOR XLPE PE | NA2XS(FL)2Y ALUMINIUM CONDUCTOR XLPE PE | |
|---|---|---|---|
| VOLTAGE |
6/10 (12)kV |
||
| CONDUCTOR |
Class 2 Stranded Aluminium |
||
| INNER SEMI-CONDUCTIVE LAYER |
Semi-Conductive Material |
||
| INSULATION |
XLPE (Cross-Linked Polyethylene) |
||
| OUTER SEMI-CONDUCTIVE LAYER |
Semi-Conductive Material |
||
| SCREEN |
Copper Wires |
Copper Wires and Tape |
|
| TAPE |
– |
Swellable Tape |
|
| OUTER SHEATH |
PE (Polyethylene) |
||
| TAPE 2 | – |
Aluminium Foil Tape Tightly Bonded to Sheath |
|
Electrical Characteristic
| CONDUCTOR MATERIAL |
Aluminium |
|---|---|
| CONDUCTOR CLASS |
Circular, Stranded Class 2 |
| INSULATION |
XLPE – Cross-linked Polyethylene |
| METALLIC SCREEN |
Copper Wire Screen – Annealed Copper Wires Helicaly Wound and Equalising Copper Tape Applied in Open Counter-helix. Plastic Tape is Applied Over Screen |
| OVERSHEATH |
LSHF Low Smoke Halogen Free Thermoplastic Compound, Polyolefin Type DMZ2 |
| OVERSHEATH COLOUR |
Black |
| CABLE DESIGNATION |
Al, Cu Tape Screen, PO, XLPE |
| TEST VOLTAGE |
3.5xUo |
| CONDUCTOR OPERATING TEMP |
90°C (nominal) to 120°C (2) |
| MAX SHORT-CIRCUIT TEMP |
250°C (t<5s) |
| AMBIENT TEMPERATURE |
Cables in Air 30°C |
| MAX PULLING FORCE (N) |
30xConductor Cross-section [mm2] Over Conductor (N) |
| BEDDING |
LSHF Low Smoke Halogen Free Thermoplastic Compound |
| FIRE RETARDANT |
Bunch of Cables Vertically Mounted on a Ladder, Length of Charred Cable <2.5m |
Packing shipping
If you have another question, pls feel free to contact us below
We are China N2xs (FL) 2y/Na2xs (FL) 2y 12/20 Kv RM 1X300/25 1X400/50mm2 Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
